ASUSTOR - ASUSTOR Lockerstor 4 AS6604T
NAS server - 4 bays - SATA 6Gb/s - RAID RAID 0, 1, 5, 6, 10, JBOD - RAM 4 GB - 2.5 Gigabit Ethernet - iSCSI support
ASUSTOR
AS6604T
0887372013629
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | ASUSTOR Lockerstor 4 AS6604T - NAS server |
| Device Type | NAS server |
| Host Connectivity | 2.5 Gigabit Ethernet |
| Max Supported Capacity | 72 TB |
| Installed Devices / Modules Qty | 0 (installed) / 4 (max) |
| Dimensions (WxDxH) | 6.7 in x 9.1 in x 7.3 in |
| Weight | 6.53 lbs () |
| Processor | 1 x Intel Celeron J4125 2 GHz (Quad-Core) |
| Storage Controller | RAID SATA 6Gb/s RAID RAID 0, 1, 5, 6, 10, JBOD |
| Networking | 2.5GbE |
| RAM | 4 GB |
| Power | AC 120/230 V |
| System Requirements | UNIX, Apple MacOS, Linux, FreeBSD, Microsoft Windows Server 2003, Microsoft Windows Server 2008, Microsoft Windows Server 2012, Microsoft Windows XP / Vista / 7 / 8 / 10, Microsoft Windows Server 2016, Microsoft Windows Server 2019 |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | NAS server |
| Host Connectivity | 2.5 Gigabit Ethernet |
| Total Storage Capacity | 0 GB |
| Max Supported Capacity | 72 TB |
| Installed Devices / Modules Qty | 0 (installed) / 4 (max) |
| Width | 6.7 in |
| Depth | 9.1 in |
| Height | 7.3 in |
| Weight | 6.53 lbs () |
| Expansion / Connectivity | |
| Expansion Bays | 4 (total) / 4 (free) - 2.5" / 3.5" |
| Expansion Slots | 2 (total) / 2 (free) x M.2 |
| Interfaces | 2 x 2.5 Gigabit Ethernet - RJ-45 ¦ 3 x USB 3.2 Gen 1 - Type A ¦ 1 x HDMI output |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Features | Built-in cooling fan, automatic sleep mode |
| Compliant Standards | VCCI, C-Tick, BSMI, CCC, FCC, KCC, BIS |
| Networking | |
| Data Link Protocol | 2.5GbE |
| Network / Transport Protocol | TCP/IP, FTP, SMB, NFS, SFTP, IPv4, IPv6 |
| Remote Management Protocol | SNMP, HTTP, HTTPS, TFTP, SSH, LDAP |
| Network Services Compatibility | Microsoft CIFS, Apple File Protocol (AFP), Web-based Distributed Authoring and Versioning (WebDAV) |
| Features | Firewall protection, VLAN support, wake on LAN (WOL), Syslog support, Jumbo Frames support, SMS alert, UPnP Media Server, e-mail notification, B-tree file system (Btrfs), EXT4 file system, Rsync compatible, wake on WAN (WOW) |
| Encryption Algorithm | 256-bit AES |
| Compliant Standards | IEEE 802.3ad (LACP), UPnP |
| Power | |
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V |
| Power Consumption Operational | 27.6 Watt |
| Power Consumption Stand by | 0.75 Watt |
| Power Provided | 90 Watt |
| Software / System Requirements | |
| OS Required | UNIX, Apple MacOS, Linux, FreeBSD, Microsoft Windows Server 2003, Microsoft Windows Server 2008, Microsoft Windows Server 2012, Microsoft Windows XP / Vista / 7 / 8 / 10, Microsoft Windows Server 2016, Microsoft Windows Server 2019 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 95% |
| Sound Emission | 17.6 dBA |
| Storage Controller | |
| Type | RAID |
| Interface Type | SATA 6Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD |
| Processor / Memory | |
| Processors Installed | 1 x Intel Celeron J4125 2 GHz |
| Number of Cores | Quad-Core |
| Max Supported Qty | 1 |
| Max Turbo Speed | 2.7 GHz |
| RAM | 4 GB (installed) / 8 GB (supported) - DDR4 |
| Flash Memory Installed | 8 GB |
